Models as software

Besides being a description of some physical system, simulation models are also software. Small models are often made by a single researcher/developer, and don’t need much structure to remain manageable. Larger and more complex models tend to stretch beyond the expertise and resources of a single researcher however, and need to be developed collaboratively over a longer period of time. Besides good scientific practice, good software engineering practice is then also needed.

A search for research software engineering best practices will find you many resources on things like using version control, testing, documentation, and so on, and so we will not go into these aspects here. (You should definitely have a look though, and apply these techniques!)

Instead, we’ll look at two aspects specific to development of MUSCLE3 models: architecture and collaborative development.

Model architecture

Since simulation models are both descriptions of the real world and also computer programs, they have two kinds of architecture. There’s the conceptual architecture, which is about which domains the modelled system consists of, which processes take place there, interactions between them, spatial and temporal scales, and so on. And there’s the software architecture, which is about how the source code implementing the model is organised.

Both of these are important for good computational science. They’re separate problems, but because the software does need to implement the concepts, they’re interrelated. Often it’s useful to arrange the software to follow the model structure, but deviations may also make sense, such as when two conceptually unrelated parts of the model can share some generic code.

Unfortunately, there’s no set of simple rules for good software design. Experience really helps, but experienced software developers are somewhat scarce in (computational) science. So you may just have to do your best, and hopefully the guidelines below can be of help.

If you do discover that a design decision you made wasn’t the best, don’t be afraid to try something else, and remember that this is exactly how those experienced software developers got their experience. With every mistake you find and fix, your software will be designed a little bit better, and its developer will be a bit better at software design.

Small models

For small MUSCLE3 models that you run yourself, you can put everything you need into a single yMMSL file, including the model, settings, programs and resources. As shown by the tutorial though, it’s often useful to split this information across multiple yMMSL files.

This will let you easily compare two different model configuration using different settings files for different runs, or you could sometimes add a file with custom implementations if you want to validate one code against another. If you use different computers and/or have different configurations that vary widely in how expensive they are to run, then you may want separate resource files as well so that you can easily give the big runs more resources.

In general, keeping things separate gives you more flexibility, and it allows you to have multiple configurations side-by-side, which is much better for reproducibility than a single constantly evolving configuration.

Layered architecture

For larger models, you’ll want to create a hierarchical model, in which some of the components are implemented by submodels, which in turn may contain more programs and submodels. Different developers can then work on different submodels, and as long as they agree on the interfaces between them they won’t break each other’s code.

Of course, this means that the model needs to be organised somehow into smaller pieces. A good way to do this is to use a layered architecture. The example from the Importing implementations section has such a layered architecture.

_images/layered_nested_rdmc.png — Layered architecture of the nested UQ model

At the bottom, there are the diffusion_cpp and reaction_cpp programs, which each implement a physical process. One layer up, there’s the reaction_diffusion model that couples them together, and then the top layer is formed by the rduq model, which also relies on the qmc model from the middle layer, which in turns sits on top of the mc_driver_cpp and load_balancer_cpp programs in the bottom layer.

Are there other ways that this model could be organised? Yes. If we look at the conceptual structure of the model, then we see that we have an ensemble of model runs. Inside of each run, there’s a slow diffusion process, at each timestep of which we run a much faster reaction simulation. This is a kind of hierarchy too, but it does not align with the way the software is arranged. There, we have UQ and reaction-diffusion sitting side-by-side in the middle layer, rather than reaction-diffusion sitting inside of (or below) the UQ part.

The latter would actually have been quite a natural thing to do. Imagine that we have the reaction_diffusion model, and that we now want to do an uncertainty quantification of it. Most researchers in this case would make an rduq model containing the mc (sampler) component and the rr (load balancer) component, connected to a third model component which is implemented by reaction_diffusion. This creates an architecture like this:

_images/layered_nested_rdmc_alt.png — Alternative layered architecture of the nested UQ model

Note that now the two hierarchies are aligned, with the reaction-diffusion model sitting below or inside the uncertainty quantification model.

(There is no yMMSL implementation available for this, but if you want, go ahead and try to create it. It’s a nice exercise!)

Is this better? It’s more natural to align the hierarchies like this, but there’s a disadvantage: the Monte Carlo sampling part of this model isn’t very reusable. It’s hard-coded to use the reaction_diffusion model, and you have to modify the code if you want to do something else with it.

The first implementation does not have this issue. Both the reaction-diffusion and uq parts of the model are components that are used by rduq in the top layer. If you wanted to use the Monte Carlo sampler with a different model, then you could make a different top layer that combines qmc with that.

Even better, you could have both top-level models in different files side-by-side, with both of them using qmc but each using a different model. Of course, you could copy-paste the top-level model of the aligned-hierarchies version too, and modify the copy to use the other simulation submodel.

However, if you then found a bug in the Monte Carlo part, then you’d have to remember to update both copies (or however many you end up having…). In the first implementation, there’s only one copy to update so that everything is always up-to-date.

This is a nice example of how software architecture typically requires some experience. If you look at existing codes in computational science, you’ll find that the latter architecture is very common, and that copy-pasting and modifying is the normal way of working. There’s usually a better option though, and it pays to try to find it.

Frameworks

There’s another fairly common way to design reusable software, and that is the framework. Where in a layered architecture we create reusable components that we can reuse by building things on top of them, a framework does the opposite: it specifies a reusable top layer that users then attach things to from the bottom.

As always, this has advantages and drawbacks. An advantage is that it’s usually easier to create a top layer than to make a reusable block for others to build things on top of, because if you make the top layer then you’re the one deciding all the concepts and how things work and everyone using your framework has to adapt to that. Making a reusable component for others to build on top of is more difficult, because it will have to be flexible enough to fit with whatever it is that they’re doing.

MUSCLE3 itself is actually an example of this. Unlike many other model coupling systems, when you connect your code to MUSCLE3 you do so through a library, which results in minimal disruption to the code structure. In contrast, there are coupling systems which require you to convert the code to a library implementing a particular API, which the coupling system and often a driver script then sit on top of. Such a framework is easier to code for the creator of the coupling system, but more work for the modeller. So this advantage is actually also a disadvantage.

Another disadvantage of frameworks is that they’re not composable. While you can and almost always will put your program or script on top of a layer containing multiple libraries, you can’t plug your code into multiple frameworks at the same time.

Does that mean that frameworks are generally a bad idea? Not necessarily. There are cases where most of the structure of an application will always be fixed, with only some flexible parts. In that case, it may make sense to build a framework, essentially a complete application with some customisation points.

How does this work in MUSCLE3? Above, we proposed an alternative architecture for the reaction-diffusion UQ example in which there is a top-level model containing the sampler and the load balancer, as well as a model component implemented by reaction_diffusion. If we take that, but remove the implementation from model, then we have a framework for uncertainty quantification:

_images/mc_framework.png — A framework for uncertainty quantification

A user would then use the framework like this:

ymmsl_version: 0.2

imports:
- from uq_framework import implementation uq
- from reaction_diffusion import implementation reaction_diffusion

custom_implementations:
  uq.model: reaction_diffusion

Here, we import the framework, and then the model, and then we use the custom_implementations feature to plug the model into the framework. The file would then contain some settings and resources as well to configure things (not shown).

Optional components

Above, we have a framework that has an extension point that has to be filled in by the user. Often when making a framework you’ll want to make those points optional. With MUSCLE3, there are two ways of doing this.

The first is to make an optionally-implemented component, by ensuring that everything connected to it can deal with the ports leading to and from the optional component not being connected.

For ports sending to the optional component this is always the case, as sends on ports that are not connected to anything are valid and will do nothing. For ports receiving from the optional component, a default message must be given in the receive call. We’ve actually already seen this in the diffusion model, which can run without a reaction model attached.

With the above set up, the optional component can then be added to the model, and connected to the other components it needs to communicate with if present. You can specify an implementation, if you want the optional component to have a default implementation, or you can leave out the implementation if you want it to be absent by default.

Users can use custom_implementations to set a different implementation if they want, and they can even unset the implementation using

custom_implementations:
  optional_component:

This looks a bit odd, not specifying a value at all, but it’s how you write None in YAML, and this syntax will override any default implementation and leave the component with no implementation at all.

MUSCLE3 will automatically remove components without an implementation, as well as any conduits attached to them, so you’ll end up with either a component with the desired implementation, or no component at all.

Sometimes having the component missing entirely isn’t what you want, for example if you want to have an optional component on a conduit in between two non-optional ones. In that case, you want to either have the component in there, with e.g. an implementation that modifies the data being sent, or you want to have the sender and the receiver connected directly to each other.

In this case, rather than removing the component entirely if it’s not needed, you can use a default implementation that simply passes the data unchanged. This is easy to implement using an empty model:

models:
  passthrough:
    ports:
      f_init: in
      o_f: out
    conduits:
      in: out

If you set this as the default implementation of a component in between the sender and the receiver, then they’ll be connected directly by default. However, if a custom_implementation changes the implementation to a program that does something to the data, then that will end up in between and the transformation is applied.

Collaborative development

When developing larger models with multiple people, the issue arises of how to exchange model code, both MUSCLE3-enabled programs and models coupling them together. If you’re all in the same project, then one option is to put everything into a single version control repository. Often however, the programs will already have their own repositories, and maybe you’re reusing a model shared by someone else without working together closely. In that case, we need a different solution.

Of course, this situation is not specific to MUSCLE3 or to making simulation models. It arises anywhere software is developed: to share your code, you need to package and distribute it.

MUSCLE3 doesn’t have a built-in packaging system and repository like Python and other modern languages do. Simulation models are often written in C++ or Fortran, which don’t have one either. Such codes are usually distributed as source code, or sometimes using a generic packaging or installation system like conda or, on HPC, environment modules.

Regardless of how you package, distribute, and install MUSCLE3 model components, they need to be made available to MUSCLE3. To do that, there need to be one or more yMMSL files with program or model descriptions, and they need to be in a place where MUSCLE3 can find them. If you’re distributing a Python package, you can also declare an Entry Point, this is described in: Python package Entry Points

In general, you can do that as follows. First, make a ymmsl/ directory somewhere in the source directory for your yMMSL files to go into. You may want to make a subdirectory in it named after your code or model, especially if you have multiple ymmsl files for the user to import from. If there’s only one thing to import, then putting a single file directly into the ymmsl/ directory works fine.

Caution

If your model or code has a somewhat generic name that is also used for other things, then it’s probably a good idea to put it inside of a subdirectory that disambiguates things and avoids name clashes. You could use ymmsl/my_organisation/ for example, or ymmsl/branch_of_science/, or you could even follow the example set by the Java programming language and use the internet domain of your organisation in reverse, like ymmsl/nl/esciencecenter/. Users can then import my_organisation.my_program for example, and avoid confusion with another program with the same name.

If you’re distributing a code, then the yMMSL file containing the program definition will probably have to be made from a template, because it will have to refer to wherever the executable ends up getting installed. Ideally, your build system will do this automatically at compile time, or if you’re using a packaging system like conda then the location needs to be adjusted at install time. There’s usually a way to achieve that, so have a look at the documentation for whatever you’re using.

With this in place, the next step is to install the ymmsl/ directory along with the rest of the software, and then to add its location to YMMSL_PATH. If the user is installing from source, then they’ll have to do that themself, and you should tell them that in the documentation.

Conda can source a script whenever a package is installed or an environment is activated, through which you can set environment variables, and for example EasyBuild also has a facility for setting environment variables. If you’re using a packaging mechanism that has this available, then you can set YMMSL_PATH automatically for the user whenever they activate the package.

The final thing to do then is to document how the user should import your program or model, and how to use it, and then they should be good to go.

Python package Entry Points

Important

This functionality requires the 0.16.0 release of ymmsl-python.
